Cisco and NetApp FlexPod Implementation and Administration (NS0-176) Free Practice Test

Question 1

An administrator has a FlexPod solution and is using OnCommand Unified Manager and OnCommand Performance Manager to monitor the FlexPod environment. Full integration has previously been configured between the two OnCommand virtual appliances; however, new performance issues are not being seen in the OnCommand Unified Manager dashboard.
In this scenario, which two settings should the administrator verify? (Choose two.)

A. Ensure that network connectivity exists between the two virtual appliances.

B. Ensure that the NetApp cluster is configured to forward SNMP data to OnCommand Performance Manager.

C. Ensure that the Event Publisher user credentials are entered correctly on the OnCommand Performance Manager appliance.

D. Ensure that OnCommand Performance Manager is licensed for use with OnCommand Unified Manager.

Correct Answer: C,D

Question 2

Exhibit:

An administrator is configuring a NetApp 8-node AFF8060 system as part of a FlexPod solution and will be cabling the system based on the recommended guidelines shown in the exhibit.
Based on this information, which switch would be used for the cluster interconnect connections?

A. Nexus 5548

B. NetApp CN1601

C. NetApp CN1610

D. Nexus 5596

Correct Answer: C

Question 3

Exhibit:

Which Cisco switch is shown in the exhibit?

A. Nexus 5548

B. Nexus 2232

C. Nexus 5596

D. Nexus 7004

Correct Answer: A

Question 4

While working on a performance related issue on your FlexPod solution, you notice an unequal distribution of traffic over the physical interfaces of a four port vPC between two Nexus 5000 switches. You would prefer a more even traffic distribution.
Which command would you use to accomplish this task?

A. ~lacp rate fast~

B. ~lacp system-priority~

C. ~hardware multicast hw-hash~

D. ~port-channel load-balance ethernet~

Correct Answer: D

Question 5

You have a NetApp clustered Data ONTAP storage system and vSphere 6 cluster. You discover that VMware VAAI for NFS is not showing as enabled on one of the five ESXi hosts in your vSphere cluster.
In this scenario, what must you do to enable VAAI for NFS on that ESXi host?

A. Install the NetApp NFS Plug-in for VMware VAAI on the ESXi host.

B. Enable VMware vStorage for NFS on the NetApp SVM.

C. Set the DataMover. HardwareAcceleratedInit advanced setting to 0 on the ESXi host.

D. Enable NFSv3 on the storage system.

Correct Answer: D

Question 6

A Cisco UCS chasis has two power suppliers connected to one PDU and two power supplies connected to another PDU. You would like to protect against the failure of one entire PDU.
In this scenario, which power policy should you configure in UCS Manager?

A. N+2

B. redundant

C. N+1

D. grid

Correct Answer: D

Question 7

The NetApp Vistual Storage Console is used to set which three setting categories on ESXi hosts? (Choose three.)

A. NFS Settings

B. Adapter Settings

C. Security Settings

D. Logging Settings

E. MPIO Settings

Correct Answer: A,B,E

Question 8

Which two are the expected outputs of network interface show? (Choose two.)

A. iSCSI IQNs

B. WW port names of Fibre Channel and FCoE logical interfaces

C. IP addresses of NAS and iSCSI logical interfaces

D. Namespace of SAN logical interfaces

E. System WW node name

Correct Answer: B,C

Question 9

You are an administrator of a UCS system. You notice that when you apply a setting that requires a reboot, the affected hardware reboots immediately without warning. You would like to reboot to be acknowledged by an administrator instead.
What should you do to accomplish this task?

A. Create aa BIOS policy.

B. Create a maintenance policy.

C. Create updating templates.

D. Create a scrub policy.

Correct Answer: B
